During the operation, the motor will drive the spindle at a constant speed to rotate through a pair of pulleys. The spindle is installed with flying blade for high speed rotation. The materials drop into the material feeding hopper through the lifter and are crushed by the flying blade rotating at high speed. Due to the function of centrifugal force, the materials will drop into the storage tank from the sieve with waist-shaped holes, and then will be transferred to the next procedure by the delivery pump.
1.Be made of high-quality stainless steel, be approved by National Food &Health Standard;
2.Advantages of whole structure design: reasonable, simple and practical, easy installation and maintenance;
3.Advantage of hammer type crushing machine: the granularity of the crushed materials is even and the size depends on the sieve with waist-shaped holes.
|
TECHNICAL PARAMETERS OF HAMMER TYPE CRUSHING MACHINE
|
·
|
Model Type
|
CPS-5
|
CPS-10
|
CPS-20
|
CPS-25
|
|
Power（Kw）
|
11
|
18.5
|
22
|
30
|
|
Hammer Number
|
24
|
33
|
42
|
54
|
|
Capacity（T/h）
|
5
|
10
|
20
|
25
|
|
Mechanical size
|
1200×1200×1800
|
1500×1500×1800
|
2000×2000×1800
|
2000×2000×1800
|
·
|
TECHNICAL PARAMETERS OF HAMMER TYPE CRUSHING MACHINE
|
·
|
Model Type
|
HCPS-0.5
|
HCPS-2
|
HCPS-5
|
|
Power（Kw)
|
1.1
|
3
|
5.5
|
|
Hammer Number
|
12
|
24
|
36
|
|
Capacity（T/h）
|
0.5
|
2
|
5
|
|
Mechanical size
|
600×600×1200
|
800×600×1200
|
800×1000×1200
|
